Single-thread, Chainstitch Basting Machine
Basting machine realizes high quality
Product features
Basting machine realizes high quality
- High efficient basting works at a sewing speed of 1,800sti/min.
- Chainstitch is continuously formed with a single thread and by a blind looper which eliminates the need for a bobbin thread refilling. In addition, the basted seam can be easily undone.
- Basting works are efficiently done with a maximum stitch length of 10mm which is easily set up by a control dial.
Basic performance
APPLICATIONS
- The basting of the front edges, edge and stand of collars, flaps of men's and ladies' suits and coats.
- The basting of the waist bands, the flies of trousers slacks, etc.
Specification
| Model name | ML-111U | |||
|---|---|---|---|---|
| Max. sewing speed | 1,800sti/min* | |||
| Max. stitch length | 10mm | |||
| Needle bar stroke | 35mm | |||
| Lift of the presser foot | By hand : 5.5mm, By knee : 12mm | |||
| Needle (at the time of delivery) | TV×7 (#14) #11~#14 | |||
| Thread take-up | Needle bar thread take up | |||
| Feed dog | 3-row feed dog | |||
| Looper | Blind looper | |||
| Lubrication | By an oiler | |||
| Lubricating oil | JUKI New Defrix Oil No.1 (equivalent to ISO VG7) | |||
| Weight of the machine | 29kg | |||
*“sti/min” stands for “Stiches per Minute”
