Single-thread, Chainstitch Basting Machine

Basting machine realizes high quality

Product features

  • Basting machine realizes high quality

    • High efficient basting works at a sewing speed of 1,800sti/min.
    • Chainstitch is continuously formed with a single thread and by a blind looper which eliminates the need for a bobbin thread refilling. In addition, the basted seam can be easily undone.
    • Basting works are efficiently done with a maximum stitch length of 10mm which is easily set up by a control dial.

Basic performance


    • The basting of the front edges, edge and stand of collars, flaps of men's and ladies' suits and coats.
    • The basting of the waist bands, the flies of trousers slacks, etc.


Model name ML-111U
Max. sewing speed 1,800sti/min*
Max. stitch length 10mm
Needle bar stroke 35mm
Lift of the presser foot By hand : 5.5mm, By knee : 12mm
Needle (at the time of delivery) TV×7 (#14) #11~#14
Thread take-up Needle bar thread take up
Feed dog 3-row feed dog
Looper Blind looper
Lubrication By an oiler
Lubricating oil JUKI New Defrix Oil No.1 (equivalent to ISO VG7)
Weight of the machine 29kg

*“sti/min” stands for “Stiches per Minute”
