| Major Features |
 |
Two Types of Quilting Foot / Drop Feed
Two types of quilting feet are supplied as standard accessories with the machine. A 1/5 Quilting Foot is used for basic quilting and the 1/4 Quitling Foot for precision sewing with 1/4 inch stitch width. |
 |
 |
The feed dog can be raised and lowered simply by depressing a switch. When quilting, the drop feed allows you to sew curved stitches with ease. |
|
|
 |
Even Feed Foot
With its reliable feed, the even feed foot ensures the machine's ability to produce beautiful seems when sewing difficult-to-feed fabrics such as georgette and velvet, as well as heavy weight materials such as leather. |
|
|
 |
Automatic Thread Trimmer
The machine is equipped with an automatic thread trimming device that stimultaneously cuts the needle and bobbin threads at the sewing end by lightly pressing the push-button. It uses the thread trimming mechanism that is similar to the industrial sewing machine type. |
|
 |
Foot Pedal Switch for Thread Trimming
As with an industrial sewing machine, the thread trimmer can be activated with the foot pedal switch. It greatly increases sewing efficiency. |
|
 |
 |
Easy Bobbin Replacement
A new bobbin case latch and an enlarged bobbin case area make it easier to remove and replace the bobbin. |
|
 |
Automatic Needle Threader
The push lever automatic needle threader easily threads the needle without eyestrain and allows you to start sewing quickly. |
|
 |
Knee Lifter Lever
The knee lifter lever allows you to lift / lower the presser foot without using your hands. |
|
 |
Adjustment of Presser Foot Pressure
Presser foot pressure can be adjusted according to the fabric being sewn by turning a regulator located on the top of the machine. |
|
 |
Heavy-Weight Materials are sewn with Ease
The speed control mechanism, operated by microcomputer, allows the machine to sew material at low speeds. This provides for accurate feed and perfect stitching when sewing heavy weight fabrics, quilting and multiple layers of materials. |
|
 |
Predetermined Stop Position of the Needle
To move the needle up or down as desired, simply press the needle up/down button. When the button is pressed continuously, the machine sews stitch by stitch at low speed. |
|
|
| Specifications |
|
ITEM |
SPECIFICATIONS |
| Sewing Speed |
Max. 1,500r.p.m |
| Stitch Length |
Max.6mm |
| Lift of the Presser Foot |
By Lever Max.9mm, by Knee Lifter Max. 12mm |
| Needle |
HAx1 (130/705H) #7-#18 (HLx5#9-#16) |
| Dimensions |
452 (W) x 350 (H) x 219 (D) (mm) |
| Weight (Machine only) |
11.5kg |
| Rated Voltage / Power Consumption |
120V / 1.4A, 100W |
| Power Consumption of the Lamp |
12V, 3W |
| Auxiliary Table (Dimentions) |
590 x 277 (mm) |
| Hook |
Horizontal-axis Full-rotary Hook |
|
|
