Major Features
Lay-in Type Thread Tension Slots
throughout the machine make threading easy and efficient. No wrappingm just follow the color coded thread path.
Automatic Rolled Hemming
can be created quickly and easily with built-in fingertip control. There is no need to change the throat plate or foot.
Cutting Width
can be adjusted quickly for perfect seams and rolled edges.
Adjustable Stitch Length
is adjudted by the knob located inside the machine within the range of 1 to 4mm.
Differential Feed
is easily controlled and adjusted by a dial located on the exterior left hand side.

Other Features
*Adjustable presser foot pressure
*Sewing light
*Upper looper converter(Option)
  UP
Sewing Pattern
4-Thread Overlock
 3-Thread Overlock 2-Thread Overcast(Option)
3-Thread Rolled Hem 3-Thread Narrow Overlock Frill 3-Thread Rolled Hem
With Diff. Feed
3-Thread Flatlock
  UP
Optional attachments

Blind Stitch Presser Foot

 Universal Blind Stitch Presser Foot Elasticator Presser Foot
 Cording Presser Foot Beading Presser Foot Curved Beading Presser Foot



Piping Presser Foot Gathering Presser Foot
  UP
Specifications
ITEM
SPECIFICATIONS
Number of Threads 2 / 3 / 4 Threads (2 thread is optional)
Needle Schmetz 130 / 705H Nm 70, 80, 90
Standard Overlock Width Left Needle: 5-7mm
Right Needle: 3-5mm
Rolled Hem: 1.8-2.2mm
Stitch Length  1-4mm (Standard: 2.5mm)
Differential Feed 0.7-2.0 Ratio
Presser Foot Lift 5mm / 7.5mm
Sewing Speed Maximum 1,500spm
  UP
Download
Download the documents of MO-114D/104D

Catalog (1.9MB)

Instruction Manual (11.3MB)
The above documents are PDF format. In order to display and print out the documents, please down load and install Acrobat Reader.
UP
The accesories list page is here.
